Hikvision DS-D42AM2-N LED Multi-function Card LED Controllers

• RS232 serial port or Gigabit Ethernet port communication
• Connected via Ethernet port before the first receiving card, between any two receiving cards, or after the last receiving card
• Timer function, able to replace a timer and delayer
• Temperature detection of the power distribution box
• 8x Channels of power switch control
• 4x Sensor ports to connect light sensors for automatic brightness adjustment, or connect other peripherals, such as temperature sensors
• 1x Audio output port

Specification

Power

• Input VoltageDC 3.3 V to 5.5 V
• Rated Current0.38 A
• Max. Consumption2.5 W

Working Environment

• Working Temperature-20 ℃ to +75 ℃ (-4 ℉ to 167 ℉)
• Working Humidity0% to 90% RH (without condensation)

General

• Dimensions (W × H × D)144.0 mm × 94.8 mm × 20.0 mm
• Net Weight164.4 g

Power Switch Control

• Rated voltage (Switch)AC 250 V / DC 30 V
• Rated current (Switch)3 A
